Timbren Axle-Less 1580Kg Galvanised with 4″ Drop 3.5K Stub Axles

Description

The 1580Kg series Axle-Less trailer suspension is not only durable but also provides a ride that’s so smooth you’ll forget you’re pulling a trailer. And because there’s no thru axle, you never need to worry about ordering the correct axle dimensions!

This 1580Kg Axle-less trailer suspension comes with outboard arms equipped with 4” drop to create the lowest trailer deck possible. It also includes our standard length stub axles for use with standard-width tires 225/75R15 or smaller. A brake flange is included in case you plan on using brakes with your trailer suspension.

If you’re planning to take your trailer off-road and/or use tires bigger than 225/75R15, we recommend you choose the 1600Kg HD line of suspensions here.

The genius of the Axle-Less trailer suspension has more to do with what’s not there than what is:

• Less hassle! Experience fewer limitations by gaining more ground clearance.
• Less time! You can retrofit any light-duty trailer without waiting for an axle that fits.
• Less road shock! You will maintain the smoothest ride with or without a load.
• Less danger! An independent suspension gives you better control of your trailer.

The Axle-Less suspension gives you more creative freedom. Now you have more options to design and build your trailer.

Shims are also supplied giving you the option to adjust, if necessary, the suspension camber specific to your trailer frame.

Polyurethane bushings – used at the pivot point on the control arm – hold the pin firmly in place, resulting in better stability and a more controlled alignment with each moving component. They are weather-resistant and made to last longer, especially in a harsh environment.

Features:

• 4” drop outboard arms to achieve lowest possible deck height
• Standard stub axles for use with standard-width tires 225/75R15 or smaller
• Brake flange included for optional brakes
• Smooth quiet ride empty & loaded
• Galvanised finish
• Easy bolt-on installation
• No thru axle

Specs:

• 1580Kg trailer suspension capacity
• Outboard arms with 4” drop and standard stub axles for tires less than 225/75R15

What’s Included In The Box?:

Each Axle-Less trailer suspension kit comes with both driver and passenger side to give you a full suspension.

• 2x suspensions
• 2x 4″ drop outboard arms with stub axles and brake flange
• Grade 8 Zinc Coated Hardware
• 8x Camber Shims
