Description
The 900Kg HD Axle-Less trailer suspension is designed specifically for off-road use. Components made from heavy-gauge steel support the increased demands of a trailer used on off-road terrain. A softer rubber spring allows for more suspension travel without compromising strength or capacity, providing you with the best ride quality to protect your cargo on and off the trail.
This premium HD Axle-less trailer suspension – designed for off-road use – comes with heavy duty outboard arms equipped with long stub axles for use with wider, off-road tires larger than 235/85R16. A brake flange is included if you plan on using brakes with your trailer suspension.
The genius of the Axle-Less trailer suspension has more to do with what’s not there than what is:
- Less hassle! You don’t have to worry about ordering the correct axle size.
- Less time! You can retrofit any medium-duty trailer without waiting for an axle that fits.
- Less road shock! You will maintain the smoothest ride with or without a load.
- Less danger! An independent suspension gives you better control of your trailer.
The added support of components made from heavy-gauge steel sets you up for a successful, worry-free, off-road and overland experience!
One of the critical components of the HD design are extra reinforcements such as gussets which give your Axle-Less suspension the added strength to withstand the kind of abuse that you’ll encounter on your off-road and overland adventure.
The Axle-Less suspension gives you more creative freedom. Now you have more options to design and build your trailer.
Technical Notes:
Shims are supplied in each Axle-Less HD kit to give you the option to adjust (if necessary) the suspension alignment and camber specific to your trailer frame.
Each hanger comes with a built-in square hole to allow a 2”x2” piece of metal tubing (which can be found at your local hardware store) to act as a cross member, giving extra strength and support. We recommend tubing with a wall thickness of at least 3mm.
Most of our Axle-Less HD suspensions use oversized stub axles. These stub axles will only work with oversized hubs and brakes. To make sure your stub axles and hubs fit together perfectly, we suggest you refer to the ACCESSORIES tab above, and purchase your Axle-Less HD suspension together with hubs and brakes.
Polyurethane bushings – used at the pivot point on the control arm – hold the pin firmly in place, resulting in better stability and a more controlled alignment with each moving component. They are weather-resistant and made to last longer, especially in a harsh environment. Furthermore, they’re better able to stand up to the grind of heavy-duty applications.
Features:
- Long slimline stub axles for use with wide off-road tyres larger than 235/85R16
- Components made from heavy-gauge steel support off-road and overland demands
- HD gussets for maximum reinforcement
- Patented Aeon® hollow rubber spring for smooth, quiet ride
- Polyurethane bushings balance out performance, durability and comfort
- Brake flange Included for optional brakes
- Smooth, quiet ride empty or loaded
- Galvanised finish
- Easy bolt-on installation
- No thru axle
Specs:
- Heavy duty 900Kg trailer suspension capacity
- Heavy duty outboard arms with long slimline stub axles for tyres larger than 235/85R16
What’s Included In The Box?:
Each Axle-Less trailer suspension kit comes with both driver and passenger side to give you a full suspension.
- 2x HD suspensions
- 2x HD outboard arms with long slimline stub axles with brake flange
- Grade 8 zinc coated hardware
- 8x camber shims
